The hydraulic transmission system is the core driving mechanism of a mini mobile scissor lift, providing smooth, powerful, and precise lifting operations. Below is a detailed explanation of how this system works, including its working principle and operational process.
1. Working Principle of the Hydraulic System
The hydraulic system operates based on Pascal’s Law, which states that pressure applied to a confined fluid is transmitted equally in all directions. This principle allows a small force at one point to generate a much larger force at another.
In a mini scissor lift, the hydraulic system consists of:
- Hydraulic Pump – Generates fluid pressure.
- Hydraulic Cylinder – Converts fluid pressure into linear motion, extending or retracting to lift/lower the platform.
- Control Valve – Directs hydraulic fluid flow to regulate movement.
- Hydraulic Fluid (Oil) – Transmits power and lubricates components.
- Reservoir & Filters – Store and clean the hydraulic fluid.
2. Working Process of the Hydraulic Transmission System
Step 1: Power Generation
- The electric motor (or engine) drives the hydraulic pump, which pressurizes the hydraulic fluid.
- The pump forces oil into the system under high pressure.
Step 2: Direction Control
- The operator uses a control valve (manual or electric) to direct oil flow:
- Lifting: Oil flows into the hydraulic cylinder, pushing the piston upward, extending the scissor arms.
- Lowering: The valve releases oil back to the reservoir in a controlled manner, allowing gravity to retract the cylinder.
Step 3: Lifting Motion
- As pressurized oil enters the hydraulic cylinder, the piston rod extends, pushing the scissor mechanism upward.
- The mechanical linkage of the scissor arms amplifies the linear motion, lifting the platform smoothly.
Step 4: Stability & Safety
- A pressure relief valve prevents system overload.
- Check valves lock the oil in place when stopping, ensuring stability at height.
Step 5: Lowering Process
- When descending, the control valve opens a return path for oil to flow back to the reservoir.
- The weight of the platform assists in pushing oil out of the cylinder, allowing a controlled descent.
3. Advantages of Hydraulic Scissor Lifts
✅ High Power-to-Weight Ratio – Small pumps generate significant lifting force.
✅ Smooth & Precise Movement – Hydraulic systems offer better control than mechanical systems.
✅ Self-Lubricating – Hydraulic oil reduces wear on moving parts.
✅ Overload Protection – Safety valves prevent damage from excessive loads.
Conclusion
The hydraulic transmission system in a mini mobile scissor lift ensures efficient, stable, and safe lifting operations. By converting fluid pressure into mechanical motion, it provides the power needed for smooth vertical movement while maintaining safety and reliability.
